Tritan - 35mm Bore Diam, 72mm OD, Double Shield Angular Contact Radial Ball Bearing - 27mm Wide, 2 Rows, Round Bore, 6,200 Lb Static Capacity, 8,500 Lb Dynamic Capacity
Item #: 35381763
Brand: Tritan
Model #: 5207 ZZ
Exact Tooling IR#: 04
Features and Benefits
Double shield refers to two shields, one on each side of the bearing. The shield is located on the outer race does not make contact with the inner race. Ideal for very high speeds, but does not prevent smaller contaminants from entering the bearing. They are more economical than seals.
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Angular Contact |
| Style | Double Shield |
| Bore Diameter (mm) | 35.00 |
| Outside Diameter (mm) | 72.00 |
| Width (mm) | 27.00 |
| Flange Type | Without Flange |
| Number of Rows | 2 |
| Bore Type | Round |
| Contact Angle | 25 |
| Housing Material | Steel |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 6200 |
| Static Load Capacity (Nm) | 27579 |
| Dynamic Load Capacity (Lb.) | 8500 |
| Dynamic Load Capacity (Nm) | 37810 |
| Ball Material | Steel |
