Indexable Insert Drills; Drill Style: PZAG; Maximum Drill Diameter (Inch): 5/8; Maximum Drill Diameter (Decimal Inch): 0.6250; Shank Type: Straight-Cylindrical; Shank Diameter (Inch): 3/4; Shank Diameter (Decimal Inch): 0.7500; Number of Drill Inserts: 2
Item #: 26307280
Brand: OSG
Model #: 52510001
Product Specifications
| Drill Style | PZAG |
| Maximum Drill Diameter (Inch) | 5/8 |
| Maximum Drill Diameter (Decimal Inch) | 0.6250 |
| Shank Type | Straight-Cylindrical |
| Shank Diameter (Inch) | 3/4 |
| Shank Diameter (Decimal Inch) | 0.7500 |
| Number of Drill Inserts | 2 |
| Drill Diameter Range (Decimal Inch) | 0.0000 to 0.7500 |
| Cutting Direction | Right Hand |
| Tool Material | Steel |
| Compatible Insert Style | ZPNT |
| Compatible Insert Size Code | 04 |
| Drill Depth by Diameter Ratio | 2xD |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Overall Length (Decimal Inch) | 4.0000 |
| Overall Length (mm) | 4.00 |
| Overall Length (Inch) | 4 |
| Series | 52510 |
| Shank Length (Decimal Inch) | 2.7500 |
| Coolant Through | Yes |
