Tritan - Radial Ball Bearings; Type: Miniature ; Style: Double Shield ; Bore Diameter (Decimal Inch): 0.1180 ; Bore Diameter (mm): 3.00 ; Outside Diameter (mm): 7.00 ; Outside Diameter (Decimal Inch): 0.2800
Item #: 19809953
Brand: Tritan
Model #: L730 ZZ SRL
Product Specifications
Radial Ball Bearings; Type: Miniature ; Style: Double Shield ; Bore Diameter (Decimal Inch): 0.1180 ; Bore Diameter (mm): 3.00 ; Outside Diameter (mm): 7.00 ; Outside Diameter (Decimal Inch): 0.2800
| Type | Miniature |
| Style | Double Shield |
| Bore Diameter (Decimal Inch) | 0.1180 |
| Bore Diameter (mm) | 3.00 |
| Outside Diameter (mm) | 7.00 |
| Outside Diameter (Decimal Inch) | 0.2800 |
| Width (Decimal Inch) | 0.2800 |
| Width (mm) | 7.11 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Static Load Capacity (Lb.) | 23 |
| Dynamic Load Capacity (Lb.) | 65 |
| Inner Ring Width (Decimal Inch) | 0.1200 |
| Minimum Operating Temperature Fahrenheit | -20 |
| Maximum Operating Temperature Fahrenheit | 212 |
