Worm Gear Clamps; Clamp Type: Fuel Injection Hose; Minimum Diameter (mm): 14.00; Minimum Diameter (Fractional Inch): 9/16; Minimum Diameter (Decimal Inch): 0.5625; Maximum Diameter (Decimal Inch): 0.6250; Maximum Diameter (mm): 16.00; Maximum Diameter (In
Item #: 85430197
Brand: IDEAL TRIDON
Model #: 52F1651
Product Specifications
| Clamp Type | Fuel Injection Hose |
| Minimum Diameter (mm) | 14.00 |
| Minimum Diameter (Fractional Inch) | 9/16 |
| Minimum Diameter (Decimal Inch) | 0.5625 |
| Maximum Diameter (Decimal Inch) | 0.6250 |
| Maximum Diameter (mm) | 16.00 |
| Maximum Diameter (Inch - Fraction - 4 Decimals) | 5/8 |
| Band Material | Carbon Steel |
| Band Width (Inch) | 45/127 |
| SAE Size | 16 |
| Band Thickness | 0.023 |
| Band Thickness | 23/1000 |
| Width (Fractional Inch) | 45/127 |
| Hex Size (mm) | 7 |
| Drive Type | Hex |
| Screw Material | Plated Carbon Steel |
| Series | 52F |
| Material Grade | Carbon Steel |
| Screw Type | Hex Head |
| Material | Carbon Steel |
| Width (mm - 2 Decimals) | 9.00 |
| Hose Size | 19/32 |
| Product Service Code | 4730 |
| UNSPSC Code | 31171712 |
| Country of Origin | China |
