Indexable Drill Insert: AOGT04DT IC08, Carbide 60 ° Square
Item #: 12696142
Brand: Iscar
Model #: 3329222
Product Specifications
| Insert Style | AOGT |
| Insert Size Code | 04 |
| Insert Material | Solid Carbide |
| Manufacturer Grade | IC08 |
| Inscribed Circle (Decimal Inch) | 0.1575 |
| Cutting Direction | Right Hand |
| Corner Radius (Decimal Inch) | 0.0157 |
| Chipbreaker | DT |
| Series | AOGT |
| Coating Process | Uncoated |
| Shape | Square |
| Number Of Cutting Edges | 2 |
| Rake | Positive |
| Primary Workpiece Material | Non-Ferrous Metal |
| Primary Workpiece Material Code | N |
| Length (Decimal Inch - 4 Decimals) | 0.2000 |
| Included Angle Degree | 60.00 |
| Thickness (Decimal Inch - 4 Decimals) | 0.0630 |
| Coating/Finish | Uncoated |
