Yuasa - 24 Position, 8" Chuck, Super Indexing Spacer - 5.87" High Centerline, 2.48" Chuck Through Hole, 6.82" OAL, 10.12" Overall Height
Item #: 09150038
Brand: Yuasa
Model #: 550-007
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Spacer Type | Super Spacer |
| Includes Chuck | Yes |
| Chuck Diameter (Inch) | 8 |
| Number of Indexing Increments | 24 |
| Centerline Height (mm) | 149.10 |
| Centerline Height (Decimal Inch) | 5.8700 |
| Chuck Through Hole Size (mm) | 63.00 |
| Chuck Through Hole Size (Decimal Inch) | 2.4800 |
| Masking Plate Divisions | 2; 3; 4; 6; 8; 12 |
| Indexing Accuracy (sec.) | 25.00 |
| Squareness - Base to Chuck (mm) | 0.02 |
| Squareness - Base to Chuck (Decimal Inch) | 0.0008 |
| Concentricity of Chuck (mm) | 0.0127 |
| Concentricity of Chuck (Decimal Inch) | 0.0005 |
| Parallelism Over Face (mm) | 0.02 |
| Parallelism Over Face (Decimal Inch) | 0.0006 |
| Overall Length (mm) | 173.23 |
| Overall Length (Decimal Inch) | 6.8200 |
| Overall Height (mm) | 257.05 |
| Overall Height (Decimal Inch) | 10.1200 |
