Abbott Workholding Products - 10" & Up Chuck Capacity, Microcentric Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Aluminum, 4-3/4mm Long x 1-1/2" Wide x 2" High
Item #: 04230447
Brand: Abbott Workholding Products
Model #: MC-10200A
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
| Product Specifications | |
|---|---|
| Jaw Type | Square |
| Material | Aluminum |
| Jaw Interface Type | Microcentric |
| Maximum Compatible Chuck Diameter (Inch) | 10 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 10.0000 |
| Maximum Compatible Chuck Diameter (mm) | 254.00 |
| Overall Height (mm) | 50.80 |
| Overall Height (Inch) | 2 |
| Jaw End Shape | Pointed |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 38.10 |
| Overall Width/Diameter (Decimal Inch) | 1.5000 |
| Overall Length (Decimal Inch) | 4.7500 |
| Overall Length (mm) | 120.65 |
| Maximum Internal Chucking Diameter (mm) | 247.65 |
| Maximum Internal Chucking Diameter (Decimal Inch) | 9.7500 |
| Minimum Internal Chucking Diameter (Decimal Inch) | 1.0000 |
| Minimum Internal Chucking Diameter (mm) | 25.40 |
| Material Grade | 2024 |
| Maximum External Chucking Diameter (mm) | 247.65 |
| Maximum External Chucking Diameter (Decimal Inch) | 9.7500 |
| Minimum External Chucking Diameter (mm) | 19.05 |
| Minimum External Chucking Diameter (Decimal Inch) | 0.7500 |
