Abbott Workholding Products - 12" & Up Chuck Capacity, Tongue & Groove Attachment, Square Soft Lathe Chuck Jaw - 3 Jaws, Steel, 2" Btw Mount Hole Ctrs, 5-1/2" Long x 2" Wide x 2" High, 5/8" & 5/8" Fastener
Item #: 04227203
Brand: Abbott Workholding Products
Model #: 12A04S
Exact Tooling IR#: 04
Features and Benefits
Pointed jaws are blanks used for smaller part diameters, allowing closer contact than square end jaws.
| Product Specifications | |
|---|---|
| Jaw Type | Square |
| Material | Steel |
| Jaw Interface Type | Tongue & Groove |
| Maximum Compatible Chuck Diameter (Inch) | 12 |
| Maximum Compatible Chuck Diameter (Decimal Inch) | 12.0000 |
| Maximum Compatible Chuck Diameter (mm) | 304.80 |
| Overall Height (mm) | 50.80 |
| Overall Height (Inch) | 2 |
| Distance Between Mount Hole Centers (mm) | 50.80 |
| Distance Between Mount Hole Centers (Decimal Inch) | 2.0000 |
| Tongue Width (Decimal Inch) | 0.8750 |
| Jaw End Shape | Pointed |
| Fastener Size (Inch) | 5/8 |
| Fastener Size (Decimal Inch) | 0.6250 |
| Number of Jaws | 3 |
| Overall Width/Diameter (mm) | 50.80 |
| Overall Width/Diameter (Inch) | 2 |
| Overall Width/Diameter (Decimal Inch) | 2.0000 |
| Overall Length (Inch) | 5-1/2 |
| Overall Length (Decimal Inch) | 5.5000 |
| Overall Length (mm) | 139.70 |
| Tapped Hole Size | 5/16-18 |
| Material Grade | 1018 |
