1-5/8″ Max Capacity A2-5 Spindle 16C Lathe Collet Chuck Drawbar Actuator, 3-1/4″ Nose Diam, 6-1/2″ OAL, 0.0002″ TIR, 5.47″ Projection
Item #: 00075283
Brand: Royal Products
Model #: 42338
Product Specifications
| Collet System | 16C |
| Spindle Size | A2-5 |
| Actuator Type | Drawbar |
| Maximum Collet Capacity (Inch) | 1-5/8 |
| Projection (Decimal) | 5.4700 |
| Overall Length (Decimal) | 6.5000; 6.5 in |
| Through Coolant | Nonthrough Coolant |
| Maximum RPM | 6000 RPM |
| Nose Diameter (Decimal) | 3.2500 |
| PSC Code | 5136 |
| TIR (Decimal Inch) | 0.0002 |
