Value Collection - 7/16" Bore Diam, 1-3/8" OD, Double Shield Semi Ground Extra Light Radial Ball Bearing - 7/16" Wide, 1 Row, Round Bore, 746 Lb Static Capacity, 1,526 Lb Dynamic Capacity
Item #: 00055491
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Semi-ground extra light ball bearings are used at up to speeds of 5,000 RPMs
Double shield refers to two shields, one on each side of the bearing. The shield is located on the outer race does not make contact with the inner race. Ideal for very high speeds, but does not prevent smaller contaminants from entering the bearing. They are more economical than seals.
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Semi Ground Extra Light |
| Style | Double Shield |
| Bore Diameter (Inch) | 7/16 |
| Bore Diameter (Decimal Inch) | 0.4370 |
| Outside Diameter (Inch) | 1-3/8 |
| Outside Diameter (Decimal Inch) | 1.3750 |
| Width (Inch) | 7/16 |
| Width (Decimal Inch) | 0.4370 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Steel |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 746 |
| Dynamic Load Capacity (Lb.) | 1526 |
| Maximum RPM | 5000 |
