Value Collection - 5/8" Bore Diam, 1-3/8" OD, Double Seal Semi Ground Extra Light Radial Ball Bearing - 7/16" Wide, 1 Row, Round Bore, 746 Lb Static Capacity, 1,526 Lb Dynamic Capacity
Item #: 00055277
Brand: Value Collection
Exact Tooling IR#: 04
Features and Benefits
Semi-ground extra light ball bearings are used at up to speeds of 5,000 RPMs
Double Seal Bearings are factory lubricated with oil or grease and designed to retain lubricants while keeping contaminates out. The seal is on each side of the bearing and is located on the outer race making some contact with the inner race.
Round bore bearings are designed for mounting on round shafts.
| Product Specifications | |
|---|---|
| Type | Semi Ground Extra Light |
| Style | Double Seal |
| Bore Diameter (Inch) | 5/8 |
| Bore Diameter (Decimal Inch) | 0.6250 |
| Outside Diameter (Inch) | 1-3/8 |
| Outside Diameter (Decimal Inch) | 1.3750 |
| Width (Inch) | 7/16 |
| Width (Decimal Inch) | 0.4370 |
| Flange Type | Without Flange |
| Number of Rows | 1 |
| Bore Type | Round |
| Housing Material | Steel |
| Snap Ring Included | Without Snap Ring |
| Static Load Capacity (Lb.) | 746 |
| Dynamic Load Capacity (Lb.) | 1526 |
| Maximum RPM | 5000 |
