Snap Jaws - Extension Step Jaws
EXTRA CLAMPING AND SUPPORT AREA
Extension Jaws are 2 inches longer for increased support. Hardened, precision ground, and available in 10 different step sizes. Expand your vise capacity with extension step jaws. Prices are pulled from our database in real time. Press Add button to see product price.
| 4 Inch Series | 6 Inch Series | 8 Inch Series | |
| Step Size | Part Number | Part Number | Part Number |
| Standard NO Step | 4ESJ-400 | 6ESJ-600 | 8ESJ-800 |
| 0.100 | 4ESJ-100 | 6ESJ-100 | --- |
| 1/8 | 4ESJ-115 | 6ESJ-115 | --- |
| .150 | --- | --- | 8ESJ-150 |
| 3/16 | 4ESJ-177 | 6ESJ-177 | --- |
| 1/4 | 4ESJ-240 | 6ESJ-240 | 8ESJ-240 |
| 5/16 | 4ESJ-302 | 6ESJ-302 | 8ESJ-302 |
| 3/8 | 4ESJ-365 | 6ESJ-365 | 8ESJ-365 |
| 1/2 | 4ESJ-490 | 6ESJ-490 | 8ESJ-490 |
| 5/8 | 4ESJ-615 | 6ESJ-615 | 8ESJ-615 |
| 3/4 | 4ESJ-740 | 6ESJ-740 | 8ESJ-740 |
| 7/8 | 4ESJ-865 | 6ESJ-865 | 8ESJ-865 |
| 1.0 | 4ESJ-990 | 6ESJ-990 | 8ESJ-990 |
| 1-1/4 | --- | 6ESJ-124 | 8ESJ-124 |
| 1-1/2 | --- | --- | 8ESJ-149 |
