Radial-Axial Toolholder
Right-Hand or Left-Hand Inch sizes can be ordered online. For mm size please call to order.
Prices are pulled from our database in real time. Press Add button to see product price.
| d1 | h1 in | h1 mm | L2 | L3 | b1 | h3 | h4 | Part Number |
| 30 | 3/4 | 20 | 70 | 18 | 70 | 28 | 38 | CNC86 36.3020R |
| 30 | 3/4 | 20 | 70 | 18 | 76 | 28 | 38 | CNC86 36.3020L |
| 40 | 1 | 25 | 103 | 25 | 85 | 32.5 | 48 | CNC86 36.4025R |
| 40 | 1 | 25 | 103 | 25 | 88 | 32.5 | 48 | CNC86 36.4025L |
| 50 | 1-1/4 | 32 | 126 | 31 | 105 | 35 | 60 | CNC86 36.5032R |
| 50 | 1-1/4 | 32 | 126 | 31 | 111 | 35 | 60 | CNC86 36.5032L |
| 60 | 1-1/4 | 32 | 138 | 31 | 125 | 42.5 | 62.5 | CNC86 36.6032R |
| 60 | 1-1/4 | 32 | 138 | 31 | 125 | 42.5 | 62.5 | CNC86 36.6032L |
| 80 | 1-1/2 | 40 | 140 | 35 | 160 | 55 | 80 | CNC86 36.8040R |
| 80 | 1-1/2 | 40 | 140 | 35 | 160 | 55 | 80 | CNC86 36.8040L |
