M12X1.75 D6 3RX 1.5P A-CS
Item #: TP251660001000
Brand: OSG USA, Inc.
Model #: 1660001000
| Product Specifications | |
|---|---|
| Thread Diameter Size (TDZ) | M12 |
| Cutting Edge Material | Carbide |
| Thread Pitch (TP) | 1.75 mm |
| Thread Tolerance Class (TCTR) | D6 |
| Thread Standard | Metric |
| Tool Type | Spiral Flute Tap |
| Overall Length (OAL) | 110 mm |
| Chamfer | 1.5P |
| Thread Cutting Part Length (THL) | 21 mm |
| Coating | Bright |
| Usable Length (LU) | 49.1 mm |
| Flute Type | Spiral |
| Connection Diameter Machine Side (DCONMS) | 9.32 mm |
| Measurement Type | Metric |
| Flute Count (NOF) | 3 |
| Series/List # | 16600 |
| Flute Helix Angle (FHA) | 15 Degrees |
