Sandvik Coromant - R39011T304 NL Grade CD10 Diamond Tipped Milling Insert - Uncoated, 3.59mm Thick, 6.8mm Inscribed Circle, 0.4mm Corner Radius
Item #: 69774479
Brand: Sandvik Coromant
Model #: 5745449
Exact Tooling IR#: 04
Features and Benefits
Diamond tips are one of the hardest cutting materials. It is brazed onto a carbide insert. Commonly used at high cutting speeds on non-ferrous metals.
| Product Specifications | |
|---|---|
| Insert Style | R390 |
| Insert Size | 11T304 |
| Material | Diamond Tipped |
| Manufacturer's Grade | CD10 |
| Coating | Uncoated |
| Width (mm) | 6.80 |
| Width (Decimal Inch) | 0.2677 |
| Length (mm) | 4.00 |
| Inscribed Circle (mm) | 6.80 |
| Thickness (mm) | 3.59 |
| Thickness (Decimal Inch) | 0.1413 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Corner Radius (mm) | 0.40 |
| Hole Diameter (mm) | 2.80 |
| Hole Diameter (Decimal Inch) | 0.1102 |
| Coating Process | PCD |
| Included Angle | 0 |
| Shape | Parallelogram |
| Insert Hand | Right Hand |
| Chipbreaker | NL |
| Maximum Depth of Cut (mm) | 4.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.1575 |
| Cutting Edge Style | Honed |
| Manufacturers Catalog Number | R390-11T304E-P4-NL CD10 |
