Tungaloy - 523002GI Grade TH10, 3mm Cutting Width Carbide Grooving Insert - 3mm Max Depth of Cut, Right Hand, 0.2mm Corner Radius, Uncoated
Item #: 47608427
Brand: Tungaloy
Model #: 6804657
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | GI |
| Insert Size | 523002 |
| Material | Carbide |
| Cutting Width (mm) | 3.00 |
| Cutting Width (Decimal Inch) | 0.1180 |
| Maximum Depth of Cut (mm) | 3.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.1180 |
| Manufacturer's Grade | TH10 |
| Coating | Uncoated |
| Insert Hand | Right Hand |
| Cutting Height (mm) | 3.00 |
| Cutting Height (Decimal Inch) | 0.1180 |
| Multi-Use Application | Grooving; Internal Grooving; Parting |
| Corner Radius (mm) | 0.20 |
| Corner Radius (Decimal Inch) | 0.0080 |
| Overall Length (mm) | 15.00 |
| Overall Length (Decimal Inch) | 0.5910 |
| Series | My-T |
| Rake Angle | 2 |
| ISO Number | GIR5230-02 |
| Manufacturers Catalog Number | GIR5230-02 |
| Overall Width (mm) | 3.50 |
| Overall Width (Decimal Inch) | 0.1380 |
| Insert Thickness (Decimal Inch) | 0.1730 |
| Insert Thickness (mm) | 4.4000 |
