Iscar - 16IR Internal Right Hand ISO Laydown Threading Insert - Grade IC08, Uncoated Carbide, 9.52mm Inscribed Circle
Item #: 46697934
Brand: Iscar
Model #: 5902483
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Material | Carbide |
| Insert Style | 16IR |
| Insert Hand | Right Hand |
| Thread Type | Internal |
| Thread Standard | ISO |
| Material Grade | Fine Grain |
| Manufacturer's Grade | IC08 |
| Internal Pitch (mm) | 1.00 |
| Pitch (mm) | 1.00 |
| Inscribed Circle (mm) | 9.52 |
| Inscribed Circle (Decimal Inch) | 0.3750 |
| Coating | Uncoated |
| Corner Radius (mm) | 0.05 |
| Corner Radius (Decimal Inch) | 0.0020 |
